8+2-Port PoE Switch Eco

General
ShellMetal material
Net Weight0.56 kg (1.23 lb)
Gross Weight0.64 kg (1.41 lb)
Dimensions (W × H × D)175.0 mm × 44.0 mm × 124.0 mm (6.89'' × 1.73'' × 4.88'')
Operating Temperature0 °C to 40 °C (32 °F to 104 °F)
Storage Temperature–40 °C to 85 °C (–40 °F to 185 °F)
Operating Humidity5% to 95% (no condensation)
Relative Humidity5% to 95% (no condensation)
Power Supply220 VAC, 50Hz, 1.5A
Max. Power Consumption60 W
Power Consumption in Idle3.4 W
Installation ModeDesk-Mounted,Wall-Mounted
Surge Protection2 KV

Network Parameters
Ports8 × 10/100 Mbps PoE port,2 × 10/100 Mbps RJ45 port
MAC Address Table2 K
Switching Capacity2 Gbps
Packet Forwarding Rate1.49 Mpps
Internal Cache0.77 Mbits

PoE Power Supply
PoE PortPoE: Ports 1 to 8
Max. Port Power30 W
PoE Power Budget60 W

Dialing Function
Long Range
Ports 1 to 8: up to 300 m.
Long range performance may vary depend on camera model or cable condition.

Approval
EMCCE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020)
SafetyCB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition), CE-LVD (EN 62368-1: 2014+A11: 2017)
ChemistryCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2018)

8× 10/100 Mbps PoE RJ45 port and 2 × 10/100 Mbps RJ45 port Whole-device PoE power of 60 W Long-range transmission supported High-priority ports supported
