8+2-Port PoE Switch

General
ShellMetal material
Net Weight0.555 kg (1.22 lb)
Gross Weight1.20 kg (2.65 lb)
Dimensions (W × H × D)217.6 mm × 103.35 mm × 27.8 mm (8.57'' × 4.07'' × 1.09'')
Operating Temperature0 °C to 40 °C (32 °F to 104 °F)
Storage Temperature–40 °C to 85 °C (–40 °F to 185 °F)
Operating Humidity5% to 95% (no condensation)
Relative Humidity5% to 95% (no condensation)
Power Supply48 VDC, 1.35 A
Max. Power Consumption65 W
Power Consumption in Idle5 W
Installation ModeDesk-Mounted,Wall-Mounted
Surge Protection6 KV

Network Parameters
Ports8 × 10/100 Mbps PoE port,2 × Gigabit RJ45 port
MAC Address Table8 K
Switching Capacity5.6 Gbps
Packet Forwarding Rate4.17 Mpps
Internal Cache4 Mbits

PoE Power Supply
PoE StandardIEEE 802.3af;IEEE 802.3at
PoE Power Pin8-pin power: 1/2(-), 3/6(+), 4/5(+), 7/8(-)
PoE PortPoE: Ports 1 to 8
Max. Port Power30 W
PoE Power Budget60 W

Dialing Function
Long Range
Ports 1 to 8 : up to 300 m.
Long range performance may vary depend on camera model or cable condition.

Approval
EMCFCC (47 CFR Part 15, Subpart B),CE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020),IC (ICES-003: Issue 7:2020),RCM (AS/NZS CISPR 32: 2015)
SafetyUL (UL 60950-1),CB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition), CE-LVD (EN 62368-1: 2014+A11: 2017)
Chemistry
CE-RoHS (201165EU);
WEEE (201219EU);
Reach (Regulation (EC) No.19072006)

8 × 10/100 Mbps PoE port, and 2 × Gigabit RJ45 port. IEEE 802.3at/af standard for PoE ports (Max. 60 W PoE output). IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z and IEEE 802.3ab standard. 6 KV surge protection for PoE ports. Up to 300 m long-range transmission. Wire-speed forwarding. Store-and-forward switching. Solid high-strength metal shell. Reliable fan-free design.
