FOVHorizontal field of view: 59.5° to 2.6° (Wide-Tele),Vertical field of view: 35.7° to 1.5° (Wide-Tele),Diagonal field of view: 66.6 to 3.0° (Wide-Tele)
ROIMain stream, sub-stream and third stream respectively support four fixed areas.
General
MaterialADC 12, PC+10% GF
DimensionsΦ 164.5 mm × 290 mm (Φ 6.48" × 11.42")
WeightApprox. 2 kg (4.41 lb)
Protection LevelIP66 Standard, TVS 4000V Lightning Protection, Surge Protection and Voltage Transient Protection
Power
12 VDC, 2.0 A and PoE (802.3 at), 42.5 to 57 VDC, 0.6 A, class4
Max.: 18 W, including max. 7W for IR
Working Temperature-30°C to 65°C (-22°F to 149°F)
Working Humidity≤ 90%
High quality imaging with 4 MP resolution
Excellent low-light performance via powered-by-DarkFighter technology
Clear imaging against strong back lighting due to 120 dB WDR technology
Pan and tilt ability enables camera to monitor zones of interest
25x optical zoom allows for closer viewing of subjects in expansive areas
Up to 100m IR range ensures safety at night
Water and dust resistant (IP66)
