Camera
Image Sensor2 MP CMOS
Max. Resolution1920 (H) × 1080 (V)
Min. Illumination0.001 Lux @ (F1.0, AGC ON), 0 Lux with white light
Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360°
Signal SystemPAL/NTSC
- Lens
- Lens Type2.8 mm, 3.6 mm, 6 mm fixed focal lens
- Focal Length & FOV
2.8 mm, horizontal FOV: 98°, vertical FOV: 51°, diagonal FOV: 115°
3.6 mm, horizontal FOV: 76°, vertical FOV: 41°, diagonal FOV: 90°
6 mm, horizontal FOV: 50°, vertical FOV: 27°, diagonal FOV: 58°
- Lens MountM12
- Illuminator
- Supplement Light TypeWhite Light
- Supplement Light RangeWhite Light Distance: Up to 20 m
- Smart Supplement LightYes
- Image
- Image Parameters SwitchSTD/HIGH-SAT/HIGHLIGHT
- Image SettingsBrightness;Mirror;Sharpness;Anti-Banding;AGC
- Frame Rate
TVI: 1080p@25fps/30fps
CVI: 1080p@25fps/30fps
AHD: 1080p@25fps/30fps
CVBS: PAL/NTSC
- Day/Night ModeColor
- Wide Dynamic Range (WDR)Digital WDR
- Image EnhancementBLC;HLC;Global
- Noise Reduction3D DNR/2D DNR
- White BalanceAuto/Manual
- Interface
- Video OutputSwitchable TVI/AHD/CVI/CVBS
- AlarmSolid Light Alarm (White Light)
- General
- Power
12 VDC ± 25%
*You are recommended to use one power adapter to supply the power for one camera.
Max. 2.4 W
- MaterialPlastic
- Dimension161.1 mm × 70 mm × 70 mm (6.34" × 2.76" × 2.76")
- WeightApprox. 229 g (0.50 lb)
- Operating Condition-40°C to 60°C (-40°F to140°F), Humidity: 90% or less (non-condensing)
- CommunicationHIKVISION-C
- LanguageEnglish
